KLUBERLUB NH1 11-222

Klüberlub NH1 11-222 is a lubricating grease based on paraffinic mineral oil and aluminium complex soap. Klüberlub NH1 11-222 is resistant to water and hot water.

Klüberlub NH1 11-222 is NSF H1 registered and therefore complies with FDA 21 CFR § 178.3570. The lubricant was developed for incidental contact with products and packaging materials in the food-processing, cosmetics, pharmaceutical or animal feed industries. The use of Klüberlub NH1 11-222 can contribute to increase reliability of your production processes. We nevertheless recommend conducting an additional risk analysis, e.g. HACCP.

Klüberlub NH1 11-222 is used for machines and installations in the food-processing and pharmaceutical industries, especially for applications where incidental contact with the food product cannot be excluded.
Typical applications are for example in rolling and plain bearings, lifting cylinders, joints, guide bars, guide rails, cam discs, seals etc.
Klüberlub NH1 11-222 is applied by brush, spatula, grease gun or grease cartridge.
To ensure perfect hygienic lubrication conditions the lube points have to be cleaned before applying Klüberlub NH1 11-222 for the first time.
If the production process does not allow cleaning, we recommend the existing grease be replaced by purging the system during relubrication.
Please do not hesitate to contact us in respect of grease miscibility, re-lubrication procedures etc.
This product is also available in our automatic lubricant dispenser Klübermatic. Please consult the application engineering experts from Klüber Lubrication to determine whether Klübermatic might be used under the conditions in your processes.

Lubricant rationalisation possible due to the product’s multiple uses
Good water resistance providing increased levels of surface protection when compared to a standard lithium EP 2 grease
NSF H1 registered supporting process reliability
ISO 21469 certified – supports the compliance with the hygienic requirements in your production.

Characteristics	Klüberlub NH1 11-222
Article number	096090
Composition, thickener	aluminium complex soap
Composition, type of oil	paraffinic mineral oil
Colour space	yellow
Texture	homogeneous
Service temperature, lower limit	-15 °C
Service temperature, upper limit	100 °C
NSF H1 registration number	137536
NLGI grade, DIN 51818	2
Worked penetration, DIN ISO 2137 / ASTM D217, 25°C, lower limit	265 0.1 mm
Worked penetration, DIN ISO 2137 / ASTM D217, 25°C, upper limit	295 0.1 mm
Dropping point, DIN ISO 2176 / IP 396	≥ 220 °C
Water resistance, DIN 51807-1, 3 h, 90°C	≤ 1 - 90 rating
Minimum shelf life from the date of manufacture - in a dry, frost-free place and in the unopened original container, approx.	24 months
